Поз.
Артикул
Описание
6
HINGED DOOR
6
FLAP SWIVELLING FLAPS OHNE LEISTE, L1120 MM
89
LOCKING CAP
92
LOCKING CAP
95
LOCKING CAP
107
BUSHING
131
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
134
SPRING PNEUMATIC SPRING 420 N
137
LOCK RING
143
RUBBER SECTION , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
143
RUBBER SECTION , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
158
HEXAGON HEAD BOLT
161
ROD. STRUTL437 MM
164
ROD. STRUTL498 MM
170
LOCK
176
SCREW , Replaced By: N910143008000
179
STRIKER
182
STRIKER
185
PLATE
380
BRACKET
380
BRACKET70X77 MM
383
SCREW , Replaced By: N914146006102
386
NUT , Replaced By: N913023006001
389
LOCK
