TOURISMO 16 RHD - 632.038 - 75 OUTSIDE FLAPS
Поз.
Артикул
Описание
9
FLAP
19
HEXALOBULAR BOLTM5X12
21
VENTILATION PART , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.08.2010
22
BRACKET
53
SCREW , Replaced By: N910143008002
56
WASHER
59
RUBBER SEAL , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
98
INSULATION , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
107
BUSHING
239
RAIL
243
ANGLE
243
ANGLE
245
FUSE JACKET TUBE WIRING HARNESS FASTENING
248
SCREW BRACKET TO COVERING
252
SPRING
255
HEXALOBULAR BOLTM5X12
