Поз.
Артикул
Описание
466
RESERVOIR40L,246 MM,8.5 BAR
468
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
468
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
470
FITTING AIR RESERVOIR,CONNECTION: "11"
472
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
472
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
474
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
474
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
478
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
480
NUT CHECK VALVE TO AIR RESERVOIR
482
LOCK (PROTECTION AGAINST TORSION),5 934167
482
LOCK PROTECTION AGAINST TORSION,5 934167
504
SUPPORT SERVICE BRAKE AIR RESERVOIR
520
STRAP , Replaced By: A6204300040
520
STRAP SERVICE BRAKE AIR RESERVOIR
520
STRAP SPRING-LOADED BRAKE AIR RESERVOIR
528
NUT STRAP TO BRACKET
528
NUT , Replaced By: N910113010000
536
BASE AIR RESERVOIR TO APPARATUS SUPPORT, BOTTOM
536
BASE AIR RESERVOIR,STRAP
540
WASHER STRAP TO SUPPORT
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
AIR CLEANERBOSCH
999
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
999
REPAIR KIT PRESSURE LIMIT VALVE
999
AIR DEHYDRATOR"WABCO",5 502947
999
RESERVOIR , Replaced By: A0034322301
999
RESERVOIR , Replaced By: A0034321401
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
ELBOW FITTING , Replaced By: A0049906471
999
VALVE (PRESSURE LIMIT VALVE)
999
T-FITTING PRESSURE RELIEF VALVE,CONNECTION: "10"
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
VALVE (OVERFLOW VALVE) WABCO
999
VALVE (OVERFLOW VALVE) GRAU
999
ELBOW FITTING CHECK VALVE TO RELAY VALVE
999
BRACKET AIR RESERVOIR TO FRAME
999
STRAP FRONT AIR RESERVOIR,RIGHT
999
STRAP AIR RESERVOIR,FOUR-CIRCUIT PROTECTIVE VALVE
999
STRAP AIR RESERVOIR
999
BRACKET AIR DEHYDRATOR,5 339169
999
STRAP AIR RESERVOIR TO BRACKET
999
STRAP AIR RESERVOIR III,5 088362
999
BRACKET AIR DEHYDRATOR,5 433280
999
BATTERY SUPPORT , Replaced By: A6205401916
999
BASE AIR RESERVOIR TO RIGHT SIDE MEMBER, INSIDE
999
SUPPORT SERVICE BRAKE AIR RESERVOIR
999
BRACKET , Replaced By: A6484320340
999
BRACKET , Replaced By: A6554318840
999
BATTERY SUPPORT
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
FITTING , Replaced By: A0009907771
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
