Поз.
Артикул
Описание
5
CONNECTOR FEED LINE TO ENGINE
5
CONNECTOR FROM ENGINE TO EXPANSION TANK
10
GASKET. SEAL DE-AERATION PIPE TO ENGINE
12
SEAL RING AT WATER PUMP
12
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0209971148
12
SEAL RING , Replaced By: A0249972848
14
BREATHER PIPE EXPANSION TANK
16
BREATHER PIPE , Replaced By: A0005516256
16
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
16
BREATHER PIPE DE-AERATION LINE
18
HOSE CONNECTION OF COOLING WATER LINES
18
HOSE DE-AERATION PIPE TO EXPANSION TANK
18
HOSE , Replaced By: A3095062535
18
HOSE PIPE LINE TO CONNECTION FITTING AND TO PRESSURE REGULATOR
20
HOSE BETWEEN DE-AERATION LINE AND EXPANSION TANK
22
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR,5 534803
22
HOSE , Replaced By: A3635060235
25
LOCKING CAP , Replaced By: A3815010144
25
COVER FROM COOLING WATER OUTLET TO WATER PUMP
27
BRACKET , Replaced By: A3224923319
27
BRACKET LINE MOUNTING, TO BE ADAPTED DURING ASSEMBLY
29
CLAMP LINE MOUNTING
32
HEXAGON HEAD BOLT. SCREW EXHAUST PIPE TO MUFFLER
32
SCREW , Replaced By: N304014008021
35
SCREW PUMP TO BRACKET M 6X20
38
NUT PUMP TO BRACKET
38
NUT , Replaced By: N913004006001
41
HOSE , Replaced By: A6175011782
41
HOSE FEED AND RETURN LINE CONNECTION
44
CLAMP HOSE TO FITTING AND TO OIL TANK
44
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
44
CLAMP , Replaced By: N000000000667
47
HOSE , Replaced By: N900271050012
47
HOSE FEED AND RETURN LINE CONNECTION, LENGTH AVAILABLE 1000 MM
50
CLAMP , Replaced By: N000000000672
50
CLAMP , Replaced By: N000000000673
50
CLAMP , Replaced By: N000000000674
50
CLAMP HOSE FASTENING 50-70X13 MM
50
CLAMP HOSE 70-90X13 MM
50
CLAMP HOSE TO RETARDER 60-80X13 MM
59
COOLING WATER PIPE FEED LINE TO ENGINE
59
LINE FEED LINE TO ENGINE
59
LINE ENGINE,LEFT
71
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
74
SCREW PLUGROCKINGER,TYP 59 U150
74
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
77
COOLING WATER PIPE FRONT LEFT
83
COOLING WATER PIPE FEED,CENTRAL
84
COOLING WATER PIPE FEED,CENTRAL
84
PIPE ELBOW FEED,CENTRAL
86
COOLING WATER PIPE FEED,CENTRAL
89
LINE FEED,CENTRAL
92
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
95
SCREW PLUGROCKINGER,TYP 59 U150
95
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
113
COOLING WATER PIPE FEED, REAR
113
COOLING WATER PIPE COOLING WATER INLET
113
COOLING WATER PIPE FEED, REAR
116
COOLING WATER PIPE FEED, REAR
128
HOSE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6565060135
128
HOSE FEED AND RETURN LINES TO RETARDER
131
BRACKET , Replaced By: A6224760136
131
BRACKET , Replaced By: A6255042340
131
BRACKET CABLE HARNESS MOUNTING
149
CLAMP LINE MOUNTING
149
CLAMP , Replaced By: A9424310043
149
CLAMP , Replaced By: N000000001641
152
SCREW , Replaced By: N304017008021
152
SCREW CONTROL VALVE
152
SCREW SHACKLE TO CONSOLE
152
SCREW PIPE CLAMP
152
SCREWM 8X40
153
LOCK WASHERROCKINGER TYP 59 G140,59 G150
155
NUT
155
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
155
NUT , Replaced By: N304032008006
155
NUT , Replaced By: N913004008001
999
COOLING WATER LINE FEED,CENTRAL
999
COOLING WATER LINE CENTRAL
999
HOSE , Replaced By: A3095062535
999
HOSE , Replaced By: A3635060235
999
SPACER TUBE CLAMP TO BRACKET
999
BUSHING , Replaced By: A6999922901
999
LINE REAR
999
LINE REAR
999
LINE REAR
999
LINE COOLING WATER INLET
999
BRACKET COOLING WATER LINE TO TRANSMISSION
999
BRACKET COOLING WATER LINE TO FRAME
999
PIPE ELBOW REAR
999
BRACKET , Replaced By: A6205240340
999
BRACKET , Replaced By: A3814923041
999
COOLING WATER LINE FEED,CENTRAL
999
BUSHING , Replaced By: A6013250453
999
SCREW CLUTCH TO FLYWHEEL
999
SCREW DE-AERATION LINE TO THERMOSTAT BRACKET M 10X120
999
CLAMP , Replaced By: N071555100501
999
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
