Поз.
Артикул
Описание
5
VALVE REAR AXLE SELF-LEVELLING DEVICE
5
SOLENOID VALVE SELF-LEVELLING DEVICE,K 186868
6
MAGNET ,K 186868
6
MAGNET ,5 760168K 154651
7
PROTECTIVE CAPWABCO
8
AIR CLEANER ,5 760168K 154651
9
MUFFLER TRAILER CONTROL VALVE
10
REPAIR KIT (SOLENOID VALVE),K 186868
10
REPAIR KITTO 388 997 88 36
11
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
14
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
17
SCREW. UNION SCREW LINE CONNECTION
20
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
20
SCREW PLUG , Replaced By: N000908022011
23
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
26
BRACKET AIR SPRING VALVE
26
BRACKET ,5 760168 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 962043, Replaced By: A6523270440
29
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
29
SCREW , Replaced By: N304017008053
32
NUT , Replaced By: N913004008001
32
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
32
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
35
SCREW , Replaced By: N304017008023
35
SCREW CABLE HARNESS MOUNTING
38
NUT , Replaced By: N913004008001
38
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
38
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
41
TRAVEL SENSOR REAR AXLE,K 186868
44
LEVER , Replaced By: A9453200627
44
LEVER TRAVEL SENSOR, TO BE ADAPTED DURING ASSEMBLY
47
BALL STUD. BALL PIVOT TOP B10X4,5 MM
50
SCREW COVER PLATE TO COVER PLATE M 6 X 12
50
SCREW , Replaced By: N304017006018
53
SCREW VALVE TO BRACKET, Replaced By: N304014008002
53
SCREW VALVE TO BRACKET
56
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
56
NUT , Replaced By: N913004008001
56
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
59
ROD , Replaced By: A0003290930, +001A0003291030, +001N304032008006, +001N304032008007, +001N900331008427
62
NUT , Replaced By: N913004008001
62
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
62
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
PULL ROD PNEUMATIC SUSPENSION CONTROL
999
NUT BALL SOCKET TO ROD
999
NUT
999
MUFFLER , Replaced By: A0004302370
999
BALL JOINT LEFT-HAND THREAD,BALL DIAMETER 10 MM
999
BALL JOINT TRAVEL SENSOR
