Поз.
Артикул
Описание
5
GROMMET LINE THRU FRAME
8
BRACKET RIGHT COMPRESSED AIR LINES
8
BRACKET LEFT COMPRESSED AIR LINES
8
BRACKET RIGHT COMPRESSED AIR LINES, Replaced By: A6554303410
8
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554303310
8
BRACKET LEFT COMPRESSED AIR LINES, Replaced By: A6554200786
11
BRACKET TWIN OIL FILTER FLANGE,FRONT
14
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
17
SCREW PIPE CLAMP
17
SCREW , Replaced By: N304017008021
20
WASHER , Replaced By: N000125008443
20
WASHER EXHAUST MUFFLER TO STRAP
23
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
23
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
23
NUT , Replaced By: N913004008001
26
BRACKET ACCORDION TUBE
26
BRACKET ACCORDION TUBE
35
SCREW END PIECE TO EXHAUST PIPE M 12X30
35
SCREW , Replaced By: N304017012020
38
NUT END PIECE TO EXHAUST PIPE
41
BRACKET ON FRAME,LEFT FRONT,K 012508
44
BRACKET BREATHER LINE TO SIDE MEMBER
47
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
47
SCREW , Replaced By: N304017008027
50
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
50
NUT , Replaced By: N913004008001
50
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
53
BRACKET FRAME MOUNTED CABLE HARNESS TO RIGHT SIDE MEMBER
71
BRACKET COMPRESSED AIR LINES,K 168169
71
BRACKET , Replaced By: A3464310440
74
SCREW , Replaced By: A0089907401
74
SCREW BRACKET TO SIDE MEMBER,K 168169
77
SCREW BRACKET TO SIDE MEMBER
77
SCREW , Replaced By: N304017010002
80
SCREW BRACKET TO LEFT SIDE MEMBER
83
NUT STRAP TO BRACKET
83
NUT , Replaced By: N910113010000
86
NUT BRACKET TO FRAME
89
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
89
BRACKET LINE TO FRONT PANEL, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 115008, Replaced By: A0002930040
90
BRACKET LINE TO FRONT PANEL
91
EDGE GUARD SECTION AT SHOCK ABSORBER BRACKET, ORDER BY THE METER
91
EDGE GUARD SECTION , Replaced By: A0019872272
98
BRACKET FUEL LINE TO BELL HOUSING
101
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
104
NUT STRAP TO BRACKET
104
NUT , Replaced By: N910113010000
110
BRACKET ,5 927465, Replaced By: A3604292940
110
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
113
BRACKET COMPRESSED AIR LINE TO CONTROL ARM,5 927466
113
BRACKET , Replaced By: A6514310240
116
SCREW , Replaced By: N304017008021
116
SCREW PIPE CLAMP
119
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
119
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
119
NUT , Replaced By: N913004008001
122
BRACKET COMPRESSED AIR LINE TO CONTROL ARM,5 927466
125
BRACKET BRACKET TO CONTROL ARM
125
CLAMP , Replaced By: A6554314640
125
BRACKET , NOT USED, Replaced By: A6554314640
128
SHEET METAL SCREW CABLE MOUNTING IN CABLE DUCT, NOT USED
230
WASHER BRACKET TO LEFT SIDE MEMBER
230
WASHER , Replaced By: A3609902340
233
LOOM TIE LINE MOUNTING 280 MM
233
LOOM TIE LINE MOUNTING
