Поз.
Артикул
Описание
119
BRAKE ANCHOR
122
SCREW BEARING BRACKET TO BRAKE ANCHOR
122
SCREW CENTRAL BEARING CROSS MEMBER TO SIDE MEMBERS
122
SCREW BRAKE ANCHOR PLATE AND SUPPORTING SLEEVE TO JOINT HOUSING M 16X145
128
PROTECTIVE PLATE
131
PROTECTIVE PLATE WITH BEAD
134
OIL BAFFLE
134
OIL BAFFLE
137
SCREW BRAKE SHOE TO BRAKE ANCHOR PLATE TO 302 420 11 16
140
BRAKE SHOE , Replaced By: A6594200119
143
ROLLER , Replaced By: A3014200039, +002A0039971548
146
BUSHING
146
BUSHING
149
PIN , Replaced By: A3074200339
152
FITTED WASHER BRAKE SHOE ROLLER
155
LOCK RING ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
158
PIN
161
BUSHING ,669845
161
BUSHING ,669845
164
LOCK RING
167
SEAL RING BRAKE SHOE PIN TO BRAKE ANCHOR
173
BRAKE LINING (PARTS KIT),REPAIR SIZE 0 (ASBESTOS-FREE BRAKE LINING 16.70 MM)
173
BRAKE LINING (PARTS KIT),STANDARD (ASBESTOS-FREE BRAKE LINING 17.0 MM
173
BRAKE LINING (PARTS KIT),REPAIR SIZE II (ASBESTOS-FREE BRAKE LINING) 19.0 MM
173
BRAKE LINING (PARTS KIT),REPAIR SIZE I (ASBESTOS-FREE BRAKE LINING) 18.0 MM
173
BRAKE LINING , Replaced By: A6954230310
173
BRAKE LINING , Replaced By: A6954230410
173
BRAKE LINING , Replaced By: A6954230510
176
RIVET , Replaced By: A3079900197
176
RIVET BRAKE LINING 15 MM
179
PIN BRAKE SHOE TO BRAKE ANCHOR PLATE,078418
182
SCREW , Replaced By: N910106010018
188
LOCK BRAKE SHOE TO BRAKE ANCHOR
191
SPRING (RELEASE SPRING)
