Поз.
Артикул
Описание
5
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
8
PLASTIC PIPE8X6 MM, ORDER BY THE METER
8
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
11
HOSE , Replaced By: A3769978182
11
HOSE , ORDER BY THE METER
11
HOSE , Replaced By: A3849977082, +001A3829907088
14
BANJO UNION FEED
14
BANJO UNION CONNECTION OF FUEL LINES
17
CONNECTOR
20
NUT. UNION NUT RETURN
23
HOLLOW SCREW
26
SEALING RING. SEAL RING ENGINE BREATHING
29
CLAMP LINE MOUNTING
32
WASHER , Replaced By: A3609902340
35
LOOM TIE , Replaced By: A3459977390
35
LOOM TIE LINE MOUNTING
35
LOOM TIE ELECTRIC CABLE MOUNTING
38
EDGE GUARD SECTION AT LEFT SIDE MEMBER 85 MM
38
EDGE GUARD SECTION AT LEFT SIDE MEMBER 85 MM
