Поз.
Артикул
Описание
7
ACCELERATOR PEDAL (PARTS KIT), RANGE OF DELIVERY INCLUDES: 1X 655 301 00 93, 3X 000965 006077
7
ACCELERATOR PEDAL , Replaced By: A6243000304
9
PAD ACCELERATOR PEDAL
12
SCREW ACCELERATOR PEDAL
18
BALL PIVOT LOAD SENSOR
24
NUT PUMP TO BRACKET
30
SHIM ACCELERATOR PEDAL
33
BOOT ACCELERATOR PEDAL
36
SCREW ACCELERATOR PEDAL TO CAB M 6X25
36
SCREW SWITCH TO FLOOR PLATE M6X16,5 220373
47
GUIDE RAIL ACCELERATOR PEDAL TO FLOOR PLATE
49
SCREW GUIDE RAIL RETROFIT M 6X35, BORE THREADED HOLES IN CAB FLOOR TO 6.5MM
51
STOP ACCELERATOR PEDAL
54
SCREW VALVE TO BRACKET
60
NUT , Replaced By: N304032008006
66
ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING
66
ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING
72
BALL SOCKET PULL ROD TO LEVER
78
NUT BALL PIVOT TO LEVER
84
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
90
BEARING TUBE CONTROL SHAFT
96
BEARING TUBE CONTROL SHAFT
102
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
108
SHAFT CONTROL
108
SHAFT CONTROL
112
BALL PIVOT
117
LEVER CONTROL
120
LEVER CONTROL
126
BALL PIVOT BOTTOM B13X5 MM
132
CLAMPING SLEEVE , Replaced By: N308752004001
132
CLAMPING PIN CONTROL LEVER TO CONTROL SHAFT, TO BE ADAPTED DURING ASSEMBLY
138
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
138
SCREW , Replaced By: N304017008021
144
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
150
NUT , Replaced By: N913004008001
156
BRACKET RELEASE SPRING
162
SCREW BRACKET TO CROSS CONNECTION STRUT
168
NUT , Replaced By: N913004008001
174
SPRING RELEASE SPRING
441
MANUAL CONTROL IDLING ADJUSTMENT
444
GUIDE MANUAL CONTROL
447
KNOB MANUAL CONTROL
450
FITTED WASHER MANUAL CONTROL
453
NUT MANUAL CONTROL
456
WIRE CABLE IDLING ADJUSTMENT
459
GROMMET TEMPERATURE GAUGE SENDER UNIT
462
BRACKET MANUAL CONTROL
462
BRACKET MANUAL CONTROL
465
BRACKET MANUAL CONTROL
468
BRACKET
468
BRACKET , Replaced By: A3813020240
480
SCREW , Replaced By: N304017006020
480
SCREW LICENSE PLATE TO BRACKET
483
SCREW REFLECTOR BRACKET TO TAIL LAMP BRACKET M 6X16, USED WITH MERCEDES-BENZ PLATFORM
486
SCREW , Replaced By: N304017006018
486
SCREW COVER PLATE TO COVER PLATE M 6 X 12
498
NUT PUMP TO BRACKET
498
NUT , Replaced By: N913004006001
507
SPHERICAL WASHER RAIL TO SCREW
510
NUT
