Поз.
Артикул
Описание
80
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
80
PLASTIC PIPE RISING PIPE 4X6 MM
81
UNION NUT
82
GLAND , Replaced By: A0019901667
83
SLEEVE LEAK LINE
84
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
85
INSULATING HOSE LINE MOUNTING, ORDER BY THE METER
86
BANJO UNION , Replaced By: N000000000364
86
BANJO UNION HEATING CONNECTION,K 169122
86
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
89
ELBOW FITTING
92
UNION NUT
95
GLAND , Replaced By: A0019901667
98
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
101
SEAL RING
104
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
107
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
110
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
110
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
116
CONNECTOR
119
DISTRIBUTOR HOSE WIDTH, 6 MM
