Поз.
Артикул
Описание
5
CONNECTOR (CONNECTING PIPE),RIGHT FRONT
5
CONNECTOR (CONNECTING PIPE),LEFT FRONT
8
SCREW BRACKET TO TRANSMISSION
8
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
11
NUT CONNECTOR TO EXHAUST MANIFOLD
11
NUT EXHAUST PIPE TO EXHAUST MANIFOLD
14
FLEXIBLE METAL TUBE FRONT EXHAUST PIPE FRONT PART TO REAR PART
17
COLLAR FRONT EXHAUST PIPE FRONT PART TO REAR PART
20
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
23
SCREW PUMP TO FRAME SIDE MEMBER M 8X40
23
SCREW , Replaced By: N304017008018
26
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
26
NUT BRACKET TO BRACKET
29
EXHAUST PIPE EXHAUST MUFFLER,LEFT
29
EXHAUST PIPE EXHAUST MUFFLER,RIGHT
38
BRACKET RIGHT EXHAUST PIPE
38
BRACKET LEFT EXHAUST PIPE
41
CLAMP AT CROSS MEMBER
44
SCREW EXHAUST PIPE TO SIDE MEMBER
44
SCREW , Replaced By: N304017010002
47
SCREW BRACKET TO SIDE MEMBER
47
SCREW , Replaced By: N910105010011
50
NUT EXHAUST PIPE TO SIDE MEMBER
50
NUT , Replaced By: N910113010000
56
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
59
SCREW EXHAUST PIPE TO SIDE MEMBER
59
SCREW , Replaced By: N304017010002
62
NUT , Replaced By: N910113010000
62
NUT EXHAUST PIPE TO SIDE MEMBER
