Mercedes A0015458728 - РАЗЪЕМ

414,408CDI,411CDI,413CDI,416CDI 904.612 FROM IDENT-NR. R337627, 5337627, A901274

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 095 RELAY,FUSEBOX AND CONTROL MODULES IN SEAT FRAME IL. 4

Поз.
Артикул
Описание
5
A0015458709
BRAKE LIGHT SWITCH STOP LIGHT
5
A0015456409
BRAKE LIGHT SWITCH STOP LIGHT, Replaced By: A0015459509
5
A0015452009
BRAKE LIGHT SWITCH STOP LIGHT, J 62572220080527809
5
A0015453109
SWITCH STOP LIGHT SWITCH
10
A2105457628
PLUG HOUSING PNEUMATIC CONTROL UNIT
15
A0035451826
CONTACT SPRING , Replaced By: A0045455326
15
A0045455326
FLAT PIN BUSHING
20
A0015450609
SWITCH PARKING BRAKE CONTROL
25
A0015458728
PIN BUSHING HOUSING BIPOLAR
30
A0155459926
PLUG SOCKET0,5-1,5 MM2 / 2,8 MM
30
A0085450426
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 0.5-1.0 MM2
30
A0075458226
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
35
N000000002035
SCREW. HEXALOBULAR BOLT COVER TO MOUNTING FRAME M5X12
40
A0065451014
SWITCH CLUTCH
40
A0045452114
SWITCH COUPLER SWITCH FOR IDLING SPEED CONTROL
45
A0315453228
PLUG HOUSING SWITCH TO CLUTCH PEDAL 2-PIN JPT2.8
50
A0035452626
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
60
A2105456128
PLUG HOUSING WIPER MOTOR ON REAR WALL 3-PIN JPT
60
A2105454128
PIN BUSHING HOUSING FUSE AND RELAY BOX,DRIVER,4-POLE
