Поз.
Артикул
Описание
520
BEARING BRACKET
520
BEARING BRACKET , Replaced By: A3414207078
522
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
524
LOCK WASHER , Replaced By: N912004010102
526
NUT BRACKET TO FRAME
528
LEVER
530
BUSHING
532
GREASE NIPPLE
534
PIN
536
LOCK RING22X1.2,TO 001 431 71 14
650
HANDLETO 341 420 00 88
652
DAMPING RING
654
SCREW
656
RATCHET ROD
658
PROTECTIVE CAP , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
660
SPACER RING , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
662
GROOVED PIN , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
664
BEARING BRACKET , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
666
GROOVED PIN
668
REPAIR KIT
670
LOCK RING
672
SCREW CLAMP TO BRACKET AND TO PIPE
674
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
676
PIN ROD TO HAND BRAKE LEVER
678
WASHER PULL ROD TO SHIFT LEVER
679
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
680
BRAKE LEVER
682
BUSHING , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
684
BEARING BRACKET
686
WASHER BRAKE LEVER TO BEARING BRACKET, 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
688
LOCK RING22X1.2,TO 001 431 71 14
690
GREASE NIPPLE
692
SCREW BRACKET TO FRAME M 10X28
694
LOCK WASHER , Replaced By: N912004010102
696
NUT BRACKET TO FRAME
698
PULL ROD
700
NUT BRACKET TO FRAME
702
END PIECE
704
PIN , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB
704
PIN , Replaced By: N001434010009
705
COTTER PIN STRAP TO BRACKET
720
PULL ROD
720
PULL ROD
720
PULL ROD FROM INTERMEDIATE LEVER TO BRAKE INTERMEDIATE SHAFT
722
ROD
724
TURNBUCKLE
726
END PIECE
728
NUT BRACKET TO FRAME
730
NUT L.H. THREAD
732
PIN , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB
732
PIN , Replaced By: N001434010009
733
COTTER PIN STRAP TO BRACKET
752
BRACKET
752
BRACKET HAND BRAKE LINKAGE
754
BRACKET
756
GROMMET AT SHOCK ABSORBER BRACKET AND AT FENDER BRACKET
758
GROMMET
760
SCREW STEERING SHAFT BEARING TO CAB M 8X20
762
BOLT. SCREW QUICK-RELEASE VALVE TO BRACKET
764
WASHER TRAILER PLUG SOCKET TO BRACKET
766
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
768
NUT TAIL LAMP TO BRACKET
999
CLAMP , Replaced By: A0003380645
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
DRAG LINK END
999
BALL SOCKET TOP
999
BALL SOCKET BOTTOM
999
SPRING
999
DUST CAP
999
SWITCH RANGE SELECTOR LOCK
999
VALVE (RELAY VALVE) WABCO
999
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO
999
VALVE , Replaced By: A0024314006
999
SPHERICAL RING REAR DISC WHEEL
999
DRAG LINK , Replaced By: A3274601605
999
BALL PIVOT
999
BOOT , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0004621796
999
BRACKET LEFT
999
BRACKET RIGHT
999
PIPE ,A 069204
999
DISC WHEEL (8-HOLE RIM), USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
SIDE RINGTO 341 400 03 02,341 400 05 02, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS A 059728 EXCEPT FOR: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
SHOULDER RINGTO 341 400 71 02,341 400 72 02
999
RESERVOIR"1,2",A 069205A 90243
999
DRAG LINK , USED WITH AIR BRAKE,FROM CHASSIS A 059729 ALSO INSTALLED ON: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059525,A 059526,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
999
DRAG LINK , Replaced By: A3454608605
999
HOSE , Replaced By: A3769978182
999
BRACKET RELEASE SPRING
999
STOP BRAKE PEDAL
999
VALVE , Replaced By: A0004320807
999
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
999
SPRING TWO-CIRCUIT BRAKE VALVE
999
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
ROD PISTON ROD
999
YOKE PISTON ROD
999
NUT
