Поз.
Артикул
Описание
13
AIR CLEANERFRAM DO BRASIL
13
AIR CLEANER"MANN DO BRASIL", 030-041 FROM IDENT NO.: 679208
23
FILTER ELEMENTTO 376 090 82 04
23
FILTER ELEMENT
33
GASKETTO 345 094 78 02
36
BRACKETTO 345 094 78 02,345 094 79 02,77 02
36
GASKET , Replaced By: A0000941027
36
BRACKET
43
ADAPTER FITTINGTO 345 094 78 02,345 094 79 02
49
NUTTO 345 094 81 02,80 02,85 02
53
THREADED NIPPLETO 345 094 78 02,345 094 79 02
56
GASKETTO 000 094 11 68,345 094 71 68
60
THREADED UNIONTO 345 094 81 02,80 02,85 02
63
FILTER BOWLTO 345 094 78 02,345 094 79 02
63
COVERTO 345 094 71 02,345 094 80 02
66
FILTER BOWLTO 376 090 96 01CICLONIZADOR
70
FILTER BOWLTO 345 094 80 02,81 02,85 02
75
VALVETO 376 090 96 01
80
FASTENERTO 376 090 96 01
83
NUT
93
SCREW
103
SEPARATORTO 374 094 00 02
113
VACUUM BOXTO 345 094 80 02,78 02,81 02
113
VACUUM BOXTO 345 094 78 02,345 094 79 02
123
NUTTO 345 094 79 02,345 094 77 02
123
NUT
133
LOCKTO 345 094 78 02,308 094 76 02
143
NUT
153
SCREW CABLE CONNECTOR TO BRACKET
163
SEAL RINGTO 345 094 78 02,345 094 79 02
173
NUTTO 345 094 78 02,345 094 79 02
176
BRACKET
183
BRACKET , 352.00/1,353,358 FROM CHASSIS 676465 ALSO INSTALLED ON 500001-599999,TYP 360 FROM CHASSIS 676465
193
SCREW BRACKET TO FRONT PANEL, 032,033,040,041,132,133,140,141 FROM CAB 1500001
203
LOCK WASHER RAIL TO BATTERY SUPPORT
213
SCREW BRACKET TO SIDE MEMBER
223
WASHER GROUND CABLE
233
LOCK WASHER , Replaced By: N912004010102
243
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
253
HOSE FROM PICO AIR CLEANER TO INTAKE MANIFOLD AT ENGINE
263
INTAKE PIPE
283
LOOM TIE. CLAMP
283
LOOM TIE. CLAMP AS REQUIRED
293
CLAMP. LOOM TIE90-110
293
CLAMP
