Поз.
Артикул
Описание
492
PIPE LINE FLUID-RESERVOIR-TO-EXPANSION-VALVE REFRIGERANT LINE
492
PIPE LINE FLUID-RESERVOIR-TO-EXPANSION-VALVE REFRIGERANT LINE
492
PIPE LINE FLUID-RESERVOIR-TO-EXPANSION-VALVE REFRIGERANT LINE, Replaced By: A9408321815
506
PIPE LINE CONDENSER-TO-FLUID-RESERVOIR REFRIGERANT LINE, Replaced By: A9408321915
506
PIPE LINE CONDENSER-TO-FLUID-RESERVOIR REFRIGERANT LINE
506
PIPE LINE CONDENSER-TO-FLUID-RESERVOIR REFRIGERANT LINE
506
PIPE LINE CONDENSER-TO-FLUID-RESERVOIR REFRIGERANT LINE
508
PIPE LINE EXPANSION-VALVE-TO-COMPRESSOR-PIPELINE REFRIGERANT LINE
508
PIPE LINE EXPANSION-VALVE-TO-COMPRESSOR-PIPELINE REFRIGERANT LINE
515
VALVE
520
CAP
525
SEAL RING FROM LIQUID TANK TO T-FITTING
530
SEAL RING HOSE TO CONDENSER 14 MM
530
O-RING HOSE TO EXPANSION VALVE 17X2
531
RUBBER RING I.D., 20.5 MM
532
RUBBER RING
551
TANK LIQUID TANK
551
TANK LIQUID TANK
560
SWITCH (PRESSURE SWITCH)
560
SWITCH ,K 157608
560
SWITCH (PRESSURE SWITCH)
570
BRACKET LIQUID TANK
572
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
