Поз.
Артикул
Описание
102
103
104
108
BRACKET BATTERY CABLE TO TRANSMISSION
109
125
SWITCH BATTERY CUT-OFF
125
SWITCH BATTERY CUT-OFF
130
131
KEY
137
COVERING BATTERY CUT-OFF,D 262514
143
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
143
HEXAGON HEAD BOLT COVERING TO CAB
143
SCREW BRACKET AND CLAMP M6X20
149
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
149
NUT BRACKET TO FIRE WALL
155
CABLE TIE310X5MM
155
CABLE TIE LINE MOUNTING 375X8.4MM
155
LOOM TIE LINE MOUNTING 280 MM
161
167
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
167
SCREW , Replaced By: N910143008002
173
NUT HORN TO BRACKET M8
245
POSITIVE CABLE FROM BATTERY I TO BATTERY II
245
245
260
260
275
POSITIVE CABLE FROM BATTERY POS. POLE TO BATTERY MASTER SWITCH 550MM
277
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR
281
SOLDERING TERMINAL POS. POLE
287
SOLDERING TERMINAL POS. POLE
293
CABLE SHOE BATTERY CABLE 10-70 MM
293
CABLE SHOE BATTERY CABLE TO BATTERY MASTER SWITCH
302
GROMMET LINE MOUNTING 10.0 MM
320
HEXALOBULAR BOLT GROUND CABLE TO GENERATOR M6X20
320
SCREW BRACKET AND CLAMP M6X20
323
NUT ENGINE MOUNTING M8
323
HEXAGON NUT. NUT , Replaced By: N913023008002
350
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
350
NUT , Replaced By: N913023010002
350
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
350
NUT , Replaced By: N913023006001
356
STUD. SCREW GROUND CONNECTION
