Поз.
Артикул
Описание
1
FILTER
2
COVERTO 001 477 13 01
2
COVERTO 001 477 14 01
3
SEAL RING FUEL FILTER COVER
4
SEAL RING (BREATHER SCREW) TO 001 477 50 01
4
SEAL RING CONTROL VALVE,5 093991
5
SCREW BREATHER TO 001 477 50 01
5
SCREW BREATHER TO 001 477 14 01
6
SEAL RING SCREW PLUG
7
SCREW REAR AXLE REGULATING SOLENOID VALVE
8
SEAL RING VALVE TO VALVE,K 025179
9
FITTINGTO 001 477 13 01
10
TS AIR FILTER ELEMENT WITH SEAL RING
10
FILTER ELEMENT , Replaced By: A0000901451
11
FILTER ELEMENT , Replaced By: A0000901451
11
TS AIR FILTER ELEMENT WITH SEAL RING
12
FILTER FUEL FILTER "HENGST",RB031294
12
FILTER , Replaced By: A0010927001
13
FILTER HEAD"HENGST"
14
FILTER ELEMENT , Replaced By: A3524700092
15
FILTER ELEMENT REPAIR KIT
15
FILTER ELEMENT , Replaced By: A0000901151
16
SEAL RING ,D 031246
18
FILTER BOWLTO 001 092 19 01
20
SEAL RING SCREW PLUG
21
SCREW BRACKET TO CROSS MEMBER
21
SCREW 3/2-WAY VALVE TO BRACKET
21
SCREW , Replaced By: N304014008009
21
SCREW FILTER BOWL TO FILTER HEAD M 8X90,841477 ONLY FOR USE WITH BOSCH DOUBLE FILTER
24
SEAL RING FUEL LINE TO FEED PUMP
26
SCREW PLUG FUEL TANK BREATHING M 14X1.5
26
SCREW PLUGTO 000 092 69 01
30
SCREW PLATE TO FRAME M 10X45
30
HEXAGON HEAD BOLT. SCREW BRACKET TO AIR INTAKE PIPE M 10X45
32
SHIM
34
SCREW PLUG FUEL TANK
34
SCREW PLUG , Replaced By: N007604014110
36
SEAL RING INJECTION PUMP
40
LINE , Replaced By: A0089975482, +002A0009904088
42
LINE , Replaced By: A0089975482
44
LINE , Replaced By: A0089975482, +002A0009904088
46
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
49
BANJO UNION , Replaced By: N000000000363
49
BANJO UNION FEED
52
BRACKET FUEL FILTER
55
BRACKET MULTI-STAGE FUEL FILTER, UP TO ENGINE 038680WITH 100 PS,UP TO ENGINE 029938AND FOR CKD 029893 WITH 110 PS,ALL WITH EXCEPTION OF 353.900 UP TO ENGIN E 082912,353.900 UP TO ENGINE 084040WITH 130 PS 80KW (110PS /DIN) 035851 95KW (130PS /DIN) 098925
57
SCREW BRACKET TO FRAME
59
SCREW OIL FILTER TO CYLINDER CRANKCASE
63
LOCK WASHER COMPRESSED AIR LINE TO BRACKET
66
SUSPENSION EYE , UP TO ENGINE 038680WITH 100 PS,UP TO ENGINE 029938AND FOR CKD 029893 WITH 110 PS,ALL WITH EXCEPTION OF 353.900 UP TO ENGIN E 082912,353.900 UP TO ENGINE 084040WITH 130 PS 80KW (110PS /DIN) 035851 95KW (130PS /DIN) 098925
69
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
72
SCREW BRACKET TO CONSOLE
72
SCREW SUPPORT TO MOUNTING PLATE,D 180260
999
SCREW , Replaced By: A4420740071
999
FILTER HEADTO 000 092 69 01
999
FILTER , Replaced By: A0010920201
999
COVER , Replaced By: A4220900112
999
SCREW , Replaced By: A0000741771
999
FILTER ELEMENT , Replaced By: A3554700092
999
SCREW , Replaced By: A0000741771
999
FILTER ELEMENT , Replaced By: A3554700192
999
FILTER , Replaced By: A0010926701
999
FUEL FILTER , Replaced By: A0014775001
999
FUEL FILTER , Replaced By: A0014775001
999
FUEL FILTER , Replaced By: A4220900252
999
FILTER ELEMENT , Replaced By: A4220900051
999
FILTER ELEMENT , Replaced By: A4220900051
999
HOUSING
999
SCREW BREATHER TO 422 090 02 52
999
WASHER
999
SCREW PLUG , Replaced By: N000908014009
999
SCREW PLUGTO 000 553 03 05,000 553 18 05,
999
SCREW BRACKET TO SIDE MEMBER M 12X40
999
SEAL RINGTO 000 553 03 05,000 553 18 05,
999
LOCK WASHER FITTING TO BRACKET
