Поз.
Артикул
Описание
5
VALVE (TRAILER CONTROL VALVE) KNORR
5
VALVEGRAU, Replaced By: A0004319513
8
REPAIR KITTO A 000 431 82 13
11
BRACKET RELAY VALVE
14
NUT HORN TO BRACKET M8
17
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X35
20
NUT BRACKET TO SIDE MEMBER M12X1.5
23
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
23
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16, VOSS 232
23
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16 ,VOSS 232
26
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
26
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
29
BRAKE LINE COUPLING
32
BRAKE LINE COUPLING LEFT
32
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
35
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
38
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
41
ADAPTER FITTING AT BRAKE LINE COUPLING
44
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
47
50
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
53
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
56
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
56
THRUST RING LOCKING VALVE
56
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
59
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
