Поз.
Артикул
Описание
10
POWER TAKE-OFF , FOR COMPONENT PARTS SEE SPARE PARTS LIST
10
P.T.O. , Replaced By: XVV65040977
10
P.T.O. , Replaced By: XVV65040633
10
P.T.O. , Replaced By: XVV65040616
10
P.T.O. , Replaced By: XVV65040318
10
P.T.O. , FOR COMPONENT PARTS SEE SPARE PARTS LIST
20
GASKET , Replaced By: A9762610180
20
GASKET P.T.O. TO TRANSMISSION
20
GASKET P.T.O. TO TRANSMISSION
30
HEXAGON HEAD BOLT P.T.O. TO TRANSMISSION M1040
30
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
40
HOUSING P.T.O.
40
HOUSING , Replaced By: A9452642301
45
TYPE PLATE HOUSING,TOP
50
GROOVED NAIL3X4,TO 000 431 94 14,000 431 96 14
55
BUSHING P.T.O. HOUSING
65
THREADED PIN HOUSING REAR M10X16
65
STUD COVER TO P.T.O. CASE M 12 X 54
65
STUD COVER TO P.T.O. CASE M12X60, TO A 945 264 03 11
70
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
75
NUT COVER TO FLANGE
80
DRIVE SHAFT P.T.O.
90
SEAL RING DRIVE SHAFT,OUTSIDE
95
SEAL RING DRIVE SHAFT,INSIDE
97
SPACER WASHER OIL PUMP, AS REQUIRED 1.05MM
97
SPACER WASHER OIL PUMP, AS REQUIRED 1.20MM
97
SPACER WASHER OIL PUMP, AS REQUIRED 0.80MM
97
SPACER WASHER OIL PUMP, AS REQUIRED 1.10MM
97
SPACER WASHER OIL PUMP, AS REQUIRED 1.30MM
97
SPACER WASHER OIL PUMP, AS REQUIRED 0.95MM
97
SPACER WASHER OIL PUMP, AS REQUIRED 1.00MM
97
SPACER WASHER OIL PUMP, AS REQUIRED 0.85MM
97
SPACER WASHER OIL PUMP, AS REQUIRED 0.90MM
97
SPACER WASHER OIL PUMP, AS REQUIRED 1.25MM
100
COVER
100
COVER REAR P.T.O.
110
GASKET COVER TO FLANGE
110
GASKET COVER TO P.T.O. CASE
115
BALL BEARING , Replaced By: A0089814125
115
BALL BEARING DRIVE SHAFT
115
BALL BEARING DRIVE SHAFT
130
RETAINING RING BEARING TO DRIVE SHAFT
135
RETAINING RING. LOCK RING BEARING TO DRIVE SHAFT
140
SLIDING COLLAR P.T.O. CONTROL
150
RING INTERMEDIATE SHAFT
150
RING INTERMEDIATE SHAFT
155
LOCK RING DRIVE GEAR
160
BALL BEARING INTERMEDIATE SHAFT
160
BALL BEARING INTERMEDIATE SHAFT
160
BALL BEARING INTERMEDIATE SHAFT
160
BALL BEARING INTERMEDIATE SHAFT
160
BALL BEARING INTERMEDIATE SHAFT
165
NEEDLE BEARING INTERMEDIATE SHAFT
165
NEEDLE BEARING INTERMEDIATE SHAFT
170
CYLINDER (SHIFTING CYLINDER)
175
GASKET SHIFTING CYLINDER TO CASE
180
HEXALOBULAR BOLT SHIFTING CYLINDER TO CASE M8X55
190
WASHER BRACKET TO CROSS MEMBER
195
PLUG TO PLUG HYDRAULIC LINE
200
PISTON P.T.O. CONTROL
205
SEAL RING PISTON
210
SEAL RING PISTON
215
INTERMEDIATE SHAFT LESS RETARDER
215
INTERMEDIATE SHAFT LESS RETARDER
215
INTERMEDIATE SHAFT WITH RETARDER
215
INTERMEDIATE SHAFT WITH RETARDER
217
HOUSING OIL PUMP
218
SEAL RING OIL PUMP HOUSING
220
SHIFTING FORK P.T.O. CONTROL
225
SPRING SLIDING COLLAR
230
SCREW PLUG TRANSMISSION CASE TO TRANSMISSION CASE
235
DOWEL PIN P.T.O. CONTROL
240
SNAP RING P.T.O. INDICATOR ACTUATION
