Поз.
Артикул
Описание
5
PART NAME MISSING CLAMP
8
PART NAME MISSING CLAMP
11
PART NAME MISSING SCREW 1/4-20
14
WASHER BRACKET TO CROSS MEMBER, INAPPLICABLE TO BM 685.458-002
17
NUT NUT
20
BRACKET COMPRESSED AIR LINE TO ENGINE BEARING BRACKET
23
PART NAME MISSING CLAMP
26
PART NAME MISSING CLAMP
32
PART NAME MISSING SCREW 1/4-20
35
WASHER BRACKET TO CROSS MEMBER, INAPPLICABLE TO BM 685.458-002
41
NUT NUT
47
BRACKET BRACKET
48
PART NAME MISSING BRACKET
50
SCREW SCREW 1/4-20,3AM 685442 50 038885
53
GROMMET
62
PART NAME MISSING CLAMP
68
PART NAME MISSING SCREW 1/4-20
74
WASHER BRACKET TO CROSS MEMBER, INAPPLICABLE TO BM 685.458-002
83
NUT NUT
86
95
PART NAME MISSING SCREW 3/8-16 F.G
98
PART NAME MISSING WASHER 3/8
104
PART NAME MISSING NUT
114
PART NAME MISSING BRACKET
116
PART NAME MISSING CLAMP
122
SCREW SCREW 1/4-20,3AM 685442 50 038885
122
PART NAME MISSING SCREW 3/8-16 F.G
128
PART NAME MISSING SPRING WASHER
134
PART NAME MISSING NUT
137
PART NAME MISSING LOOM TIE
137
LOOM TIE LINE MOUNTING
149
INSULATION. EDGE GUARD SECTION LINE TO CROSS AND SIDE MEMBERS, ORDER BY THE METER
