Поз.
Артикул
Описание
10
10
LOCKING MECHANISM CAB,REAR LEFT AND RIGHT, FOR COMPONENT PARTS SEE SPARE PARTS LIST
15
15
16
PLUG HOUSING 3-POLE
17
FLAT PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 0.5-1.0 MM2
17
WIRE SEAL
18
19
INSULATING HOSE HOSE LINE PROTECTION 10 MM, ORDER BY THE METER
30
HEXAGON HEAD BOLT. SCREW THROTTLE HOUSING TO FRONT EXHAUST PIPE M 12X70
40
NUT BRACKET TO SIDE MEMBER M12X1.5
70
75
PIN LOCK ON SUPPORT
80
WASHER LOCK ON SUPPORT
85
CLIP STRAP TO SUPPORT
110
SHOCK ABSORBER (VIBRATION ABSORBER) CAB REAR CENTRAL SUSPENSION, FOR COMPONENT PARTS SEE SPARE PARTS LIST
115
RUBBER MOUNTINGFICHTEL&SACHS
120
120
SPACER TUBE PROTECTIVE PLATE, TO BE ADAPTED DURING ASSEMBLY
122
122
SHOCK ABSORBER (VIBRATION DAMPER) CAB MOUNTING, REAR AT SIDE, FOR COMPONENT PARTS SEE SPARE PARTS LIST
123
MOUNTING TOP 40/50 MM
123
MOUNTING TOP AND BOTTOM 40/50MM, Replaced By: A0008903101
127
HEXAGON HEAD BOLT SHOCK ABSORBER TO CONSOLE,BOTTOM M12X1.5X80
132
HEXAGON HEAD BOLT. SCREW SPACER TUBE BETWEEN STABILIZER SHACKLES M14X1,5X80,D 228766
134
NUT BRACKET TO SIDE MEMBER M12X1.5
135
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
140
145
150
150
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
150
150
150
155
160
HEXAGON HEAD BOLT. SCREW SUPPORT TO FRAME M14 X 1.5 X 140
160
SCREW. HEXALOBULAR BOLT MOUNTING FRAME TO SUPPORT M 8X30
160
HEXAGON HEAD BOLT SHOCK ABSORBER TO CONSOLE,BOTTOM M12X1.5X80
160
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
160
HEXAGON HEAD BOLT TOWING EYE TO FRAME M12X1.5X100
170
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
170
NUT HORN TO BRACKET M8
170
NUT BRACKET TO SIDE MEMBER M12X1.5
