Поз.
Артикул
Описание
12
SEAT FRAMEWORK LEFT, SUSPENSION SEAT
12
SEAT FRAMEWORK RIGHT, SUSPENSION SEAT
13
BELLOWS. BOOT LEFT, SUSPENSION SEAT
13
BELLOWS RIGHT
14
PLUG. STOP PLUG CV BOOT, SET10 PIECES
15
FRAME LEFT, SUSPENSION SEAT
15
FRAME RIGHT FRONT SEAT
16
SPRING (PARTS KIT),ATTACHMENT CLIP
17
17
17
17
17
17
18
SCREW , Replaced By: A0009903610
18
SCREW. BOLT STRUT TO FRAME, RIGHT, Replaced By: A0009903610
19
PARTS KIT BACKREST TO SEAT FRAME,RIGHT
20
20
20
20
20
20
20
20
20
20
20
20
23
BUSHING HEAD RESTRAINT, RIGHT
26
26
29
29
FASTENER , Replaced By: A0018609969
29
FASTENER , Replaced By: A0028600169
29
29
29
FASTENER , Replaced By: A0028600069
32
PLUG
32
LOCKING CAP. CAP , NO.9051I.......I.......I.......I.......I....... I, Replaced By: A6319973286
35
PUMP LUMBAR VERTEBRA SUPPORT
38
BACKREST ADJUSTER. HANDLE BACKREST ADJUSTER (PARTS KIT) RECHTS, R 25731520010326525731520010326
38
HANDLE BACKREST ADJUSTER (PARTS KIT) LINKS, R 25731520010326
41
FOLLOWER ,R 257315 BACKREST ADJUSTER: WITH BUTTON
41
FOLLOWER ,R 257315 BACKREST ADJUSTER: WITH BUTTON
42
BACKREST ADJUSTER BACKREST ADJUSTER (PARTS KIT) RECHTS, R 25731620010327
44
HANDLE SEAT CUSHION DEPTH ADJUSTMENT (PARTS KIT) LINKS, 3020 SB1/SB2/SB3/SB4QFT904A9000 MEDIUM RED
44
HANDLE SEAT CUSHION DEPTH ADJUSTMENT (PARTS KIT) RECHTS, 3020 SB1/SB2/SB3/SB4QFT903A9000 MEDIUM RED
47
HANDLE SEAT CUSHION DEPTH ADJUSTMENT
47
HANDLE SEAT CUSHION DEPTH ADJUSTMENT
47
50
HANDLE SEAT HEIGHT ADJUSTMENT,FRONT,....... I ....... I I NO.3020 I I
50
HANDLE SEAT HEIGHT ADJUSTMENT,FRONT,....... I ....... I I NO.3020 I I
53
HANDLE SEAT HEIGHT ADJUSTMENT,REAR, 3020 SB1/SB2/SB3/SB4QFT903A9000 MEDIUM RED
53
HANDLE RIGHT SEAT HEIGHT ADJUSTMENT,REAR, 3020 SB1/SB2/SB3/SB4QFT904A9000 MEDIUM RED
56
HANDLE BACKREST ADJUSTER, R 25731520010326 3020 SB1/SB2/SB3/SB4QFT905A9000 MEDIUM RED
56
HANDLE BACKREST ADJUSTER, R 25731520010326 3020 SB1/SB2/SB3/SB4QFT905A9000 MEDIUM RED
57
HANDLE BACKREST ADJUSTER, R 25731620010327525731620010327
57
HANDLE BACKREST ADJUSTER, R 25731620010327525731620010327
59
SLIDING JAW SEAT CUSHION DEPTH ADJUSTMENT
62
SPRING
62
SHOCK ABSORBER
65
SPRING VERTICAL BLOCKING
68
LEVER VERTICAL BLOCKING
71
HANDWHEEL LEFT SEAT
71
HANDWHEEL
74
RUN FORE-AND-AFT ADJUSTMENT
77
COVERING , Replaced By: A0009102239
77
COVERING , Replaced By: A0009102339
77
PANELLING LEFT
77
PANELLING. PANELING RIGHT
78
80
SCREW SPRING STOP
80
SCREW , Replaced By: N000912008219
80
SCREW BRACKET MOUNTING M6 X 20
83
WASHER SEAT MOUNTING
86
PLUG HOUSING 4-POLE
89
PLUG WITH DETENT AND WITH CATCH FOR HOUSING 0.3-0.8 MM2
89
PLUG WITH DETENT AND WITH CATCH FOR HOUSING 0.3-0.8 MM2
89
FLAT PLUG WITH DETENT 4-6 MM2
999
