Поз.
Артикул
Описание
4
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
7
LINE CLUTCH 8 X 1, LENGTH AVAILABLE 3000 MM
7
LINE CLUTCH 8 X 1, LENGTH AVAILABLE 3000 MM
9
LINE EXHAUST BRAKE, LENGTH AVAILABLE: 3000 MM
11
GROMMET CLUTCH LINE TO BRACKET
13
FITTING , Replaced By: A0029905971
13
FITTING (PARTS KIT),LINE RUPTURE
17
SEAL RING LINE CONNECTION
20
FITTING AIR RESERVOIR,CONNECTION: "13"
23
VALVE , Replaced By: A0024311206
23
VALVE (PRESSURE RELIEF VALVE)
23
VALVE PRESSURE LIMIT
26
VALVE , Replaced By: A0004299244
26
VALVE
30
VALVE (QUICK-RELEASE VALVE)
34
REPAIR KITTO 000 429 40 44
36
SEAL RING LINE CONNECTION
39
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
39
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
42
FITTING SHUTTLE VALVE,CONNECTION: "20"
45
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
49
FITTING BRAKE LINE COUPLING,CONNECTION: "11,12"
53
SCREW PLUG , Replaced By: N000908022011
53
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
56
T-FITTING REAR AXLE BRAKE CIRCUIT
60
NUT CHECK VALVE TO AIR RESERVOIR
65
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
69
O-RING CHECK VALVE TO AIR RESERVOIR
73
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
78
SCREW , Replaced By: N304017008028
83
WASHER , Replaced By: N000125008443
83
WASHER EXHAUST MUFFLER TO STRAP
86
NUT BRACKET TO SIDE MEMBER
90
SCREW BRACKET TO TAIL LAMP BRACKET
94
VALVE (PARKING BRAKE VALVE)
98
REPAIR KITTO 000 430 54 81
104
SEAL RING FUEL LINE TO FEED PUMP
108
FITTING LINE CONNECTION
116
CLAMP ,K 147121, Replaced By: N000000000319
116
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
116
CLAMP SENSOR CABLE TO BRACKET
999
999
DIAPHRAGMWABCO
999
SEAL RING , Replaced By: A0159970448
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
PIN BUSHING , Replaced By: A0075458226
999
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
999
REPAIR KIT PRESSURE LIMIT VALVE
999
PIN BUSHING HOUSING. PLUG HOUSING FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH
999
PIN BUSHING HOUSING BIPOLAR
999
SEALING CORD BRAKE POWER REGULATOR
999
LOOM TIE LINE MOUNTING 280 MM
999
LOOM TIE LINE MOUNTING
999
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
999
PIN BUSHING HOUSING UNIPOLAR
999
SEAL RINGWABCO
999
ELECTRIC CABLE
999
COVERING HAND BRAKE VALVE
999
SHIM HAND BRAKE VALVE
999
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
SCREW CAB FLOOR COVERING M 6X25
999
999
SCREW HAND BRAKE VALVE
999
GLAND LINE CONNECTION
999
SHEET METAL SCREW COVERING TO TACHOGAPH
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
NUT , Replaced By: N910113006001
999
UNION NUT LINE CONNECTION
