Поз.
Артикул
Описание
134
SCREW VALVE TO SIDE MEMBER M 8X150
134
SCREW , Replaced By: N304014008022
140
NUT , Replaced By: N304032008006
140
NUT
143
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
143
SPRING WASHER , Replaced By: N000137008212
146
SCREW PLUG , Replaced By: A0009972632
147
SCREW PLUG , Replaced By: N000910024000
148
SEAL RING OIL FILLING AND OIL DRAIN
158
161
SCREW DIODE CASE TO OPERATING UNIT CASE
164
167
170
173
173
NUT MOUNTING PARTS
176
182
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM,5 999999K 040105
185
HOLLOW SCREW. SCREW GOVERNOR-PRESSURE/MODULATION-PRESSURE MEASURING CONNECTION,012578
185
HOLLOW SCREW GOVERNOR-PRESSURE/MODULATION-PRESSURE MEASURING CONNECTION,012578, Replaced By: N000000004895
188
SEAL RING SCREW PLUG
