Поз.
Артикул
Описание
10
HOSE LINE AIR COMPRESSOR LINE
15
PLATE ENERGY DISTRIBUTOR IN BATTERY/ EQUIPMENT CARRIER, TO BE ADAPTED DURING ASSEMBLY
20
SHIM BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER 13 MM
20
SHIM BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
20
SHIM APPARATUS SUPPORT TO FRAME SIDE MEMBER 31MM
20
SHIM BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER 24MM
25
PAD MOUNTING PARTS
25
SHIM MOUNTING PARTS 30MM
25
SHIM MOUNTING PARTS 10 MM
30
SHIM MOUNTING PARTS
35
BASE MOUNTING PARTS 10MM
37
SUPPORT LEFT
37
SUPPORT RIGHT
40
BRACKET MOUNTING PARTS
40
BRACKET MOUNTING PARTS
45
BRACKET LEFT
50
BRACKET BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
60
BRACKET AT SIDE MEMBER
65
BRACKET BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
70
BRACKET LINE MOUNTING
75
BRACKET LINE MOUNTING
80
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
100
BUSHING TOOL BOX TO FRAME, TO BE ADAPTED DURING ASSEMBLY
100
BUSHING , Replaced By: A4403220150
110
BRACKET LINE MOUNTING
120
BRACKET GUIDE FOR BREATHER LINE AT APPARATUS SUPPORT
130
STRAP AIR RESERVOIR
140
BRACKET SENSOR CABLE TO BRAKE HOSE
150
SENSOR CABLE (SENSOR CABLE) BRAKE WEAR INDICATOR, REAR, AXLE, LEFT 3000MM
150
ELECTRIC CABLE BRAKE LINING WEAR INDICATOR 3000MM
