Поз.
Артикул
Описание
10
CONNECTING ROD ,082679
10
CONNECTING ROD
20
BUSHING ,082678
20
BUSHING ,082679
25
SCREW CONNECTING ROD COVER TO CONNECTING ROD, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
30
NUT
35
BEARING SHELL CONNECTING ROD BEARING SHELLS,31.90 MM STANDARD SIZE I,082679
35
BEARING SHELL PARTS KIT,REPAIR SIZE III 31.25 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
35
BEARING SHELL STANDARD,082678
35
BEARING SHELL STANDARD SIZE I 31.90 MM
35
BEARING SHELL PARTS KIT,REPAIR SIZE II 31.50 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
35
BEARING SHELL REPAIR SIZE II 31.50 MM
35
BEARING SHELL CONNECTING ROD BEARING SHELLS,32.00 MM STANDARD SIZE,082679
35
BEARING SHELL REPAIR SIZE III 31.25 MM
35
BEARING SHELL REPAIR SIZE I 31.75 MM
35
REPAIR KIT , Replaced By: A3521312133
35
REPAIR KIT , Replaced By: A3521312233
35
REPAIR KIT , Replaced By: A3521312333
35
REPAIR KIT , Replaced By: A3521312433
35
REPAIR KIT , Replaced By: A3521312533
35
REPAIR KIT , Replaced By: A3521312633
35
REPAIR KIT , Replaced By: A3521312733
35
REPAIR KIT , Replaced By: A3521312833
35
REPAIR KIT , Replaced By: A3521312933
35
BEARING SHELL PARTS KIT,REPAIR SIZE I 31.75 MM, UP TO ENGINE 238225 YEAR OF MANUFACTURE 1992
45
CYLINDER LINER WITH PISTON
45
CYLINDER LINER THREE-HOLE MOUNTING,WITH PISTON 77.00 MM, UP TO ENGINE 283201 YEAR OF MANUFACTURE 1978
55
PISTON PIN
60
LOCK RING
65
SCREW , Replaced By: N910105008005
65
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
70
GASKET , Replaced By: A3211310080
70
GASKET , Replaced By: A3211310180
70
GASKET AS REQUIRED 0.30 MM,085523
70
GASKET AS REQUIRED 0.50 MM,085523
72
FITTING AIR COMPRESSOR AND OIL PAN
78
SEAL RINGTO 376 131 74 01
80
NUT , Replaced By: N080705022002
170
CYLINDER HEAD
205
SPRING CASE
210
WASHER
215
VALVE DISC
220
VALVE DISC
225
VALVE DISC
230
SPRING
235
VALVE AIR COMPRESSOR CYLINDER HEAD
235
REPAIR KIT AIR COMPRESSOR CYLINDER HEAD
235
REPAIR KIT , Replaced By: A3521300020
245
GASKET
245
GASKET
245
GASKET CYLINDER HEAD TO CYLINDER LINER 1.00 MM
255
SCREW , Replaced By: N304017008024
255
SCREW BRACKET TO EXHAUST PIPE BRACKET
262
FITTING AIR COMPRESSOR AND OIL PAN
263
NUT , Replaced By: N080705022002
264
SEAL RINGTO 376 131 74 01
295
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
300
SEAL RING LINE CONNECTION
305
HOLLOW SCREW
310
CLAMP , Replaced By: N000000000667
310
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
320
CLAMP BREATHER LINE TO OIL SEPARATOR
325
INTAKE PIPE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR
330
INTAKE PIPE FROM VACUUM PUMP TO OIL PAN
999
PISTON RING , Replaced By: A0001317811
999
PISTON RING , Replaced By: A0001317811
999
PISTON RING , Replaced By: A0001317811
999
PISTON RING , Replaced By: A0001317811
999
CLAMP
999
LOOM TIE
999
LOOM TIE , Replaced By: N916017020000
999
FLANGE
999
INTAKE PIPE FROM CYLINDER HEAD COVER TO AIR COMPRESSOR
999
CYLINDER LINER , Replaced By: A3401300008
999
INTAKE PIPE FROM AIR COMPRESSOR TO CYLINDER HEAD COVER
999
BANJO UNION , Replaced By: A0009908488
999
PIPE BEND AT OIL PAN
999
PIPE BEND AT AIR COMPRESSOR
999
CYLINDER LINER , Replaced By: A3521311602
999
GASKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 082678, Replaced By: A3521310480
999
CYLINDER LINER , Replaced By: A3141310102
999
VALVE (PRESSURE VALVE)
999
CYLINDER LINER STANDARD
999
REPAIR KIT , Replaced By: A3521312033
999
GASKET
999
CAP TO PLUG AIR COMPRESSOR OPENING,128243
