Mercedes N000000001069 - Шайба м14

OM 457 LA 457.924

01 ENGINE HOUSING - 015 CYLINDER CRANKCASE,COVER,GASKET KIT IL. 1

Поз.
Артикул
Описание
220
A4039970230
SCREW PLUG
240
N000000001073
SEAL RING
400
N917003026003
SEAL. GASKET , Replaced By: A3661880880
410
A0059904504
SCREW OIL COOLER TO OIL FILTER M 8X38
410
N910105008011
SCREW STOP TO BATTERY CASE
430
A6019970230
SCREW PLUG , Replaced By: A1119970330
440
N000000001069
SEALING RING
470
A4031840132
VALVE
480
A4039930201
SPRING BY-PASS VALVE
490
A4031840156
SCREW PLUG
490
N000000001073
SEAL RING
570
A4421880580
GASKET OIL FILTER HEAD & OIL COOLER COVER WITH OIL COOLER TO CRANKCASE
570
A4571880280
GASKET OIL COOLER HOUSING TO CYLINDER CRANKCASE
590
N910105010029
HEXAGON HEAD BOLT P.T.O. TO TRANSMISSION M10X150
590
N910105010007
SCREW BRACKET TO SIDE MEMBER M10X35
