Mercedes A0045455226 - Розетка

G320 / G3.6 AMG 463.231 FROM IDENT-NO.106740

54 ELECTRICAL EQUIPMENT AND INSTRUMENTS - 420 MAIN CABLE HARNESS IL. 2

Поз.
Артикул
Описание
116
A4635407010
CABLE HARNESS HEATED WINDSHIELD
119
A6015450026
PIN BUSHING HOUSING BIPOLAR
122
A0135453028
PIN BUSHING HOUSING SWITCH
125
A0125451228
PIN BUSHING HOUSING PRE-GLOW TIME RELAY, 5-POLE
128
A0025450926
ROUND PIN BUSHING , Replaced By: A0025459926
128
A0025459926
ROUND PIN BUSHING2.5 MM2
131
A0015453726
PIN BUSHING
131
A0035452626
ROUND PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2.5 MM2
134
A0045455226
CONTACT SPRING1-2.5 MM2
137
A0009881678
CLIP HOSE TO CAB,4 238841
137
A0009881878
CLIP CABLE HARNESS TO ROOF RAIL
140
A0009956044
CLAMP BOWDEN CABLE TO CAB
