Поз.
Артикул
Описание
4
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
4
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
8
SEAL RINGTO 000 434 21 01
12
SPRINGTO 000 434 21 01
16
STRAINERTO 000 434 21 01
18
CUP 3/2-WAY VALVE WABCO
20
HANDLETO 000 434 23 01
21
SEAL RINGTO 000 434 23 01
22
SEAL RINGTO 000 434 23 01
24
REPAIR KIT 3/2-WAY VALVE WABCO
24
REPAIR KIT 3/2-WAY VALVE BOSCH
32
SPRING WASHER AT CAB FLOOR
34
NUT SUCTION LINE TO OIL PUMP
38
HOLLOW SCREW HEATING CONNECTION
40
SEAL RING LINE CONNECTION
46
FITTING LINE CONNECTION
46
FITTING LINE CONNECTION, Replaced By: N000000006446
58
BREATHER , Replaced By: A3933280065
58
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
58
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
60
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
62
FITTING , Replaced By: A0029905971
62
FITTING (PARTS KIT),LINE RUPTURE
64
UNION NUT LINE CONNECTION
68
GLAND LINE CONNECTION
72
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
72
BANJO UNION , Replaced By: N915052006013
76
BANJO UNION , Replaced By: N915052004006
76
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
80
SLEEVE LINE CONNECTION
80
SLEEVE , Replaced By: N915062006000
82
FITTING 3/2-WAY VALVE
84
T-FITTING EXHAUST BRAKE LINE CONNECTION
86
ANGLE LINE MOUNTING
90
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
90
PLASTIC PIPE RISING PIPE 4X6 MM
92
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
94
UNION NUT
96
SEAL CONE
96
GLAND , Replaced By: A0019901667
98
BUSHING , Replaced By: N915062004000
98
SLEEVE LEAK LINE
100
LOOM TIE LINE MOUNTING
104
DISTRIBUTOR EXHAUST BRAKE VALVE LINE CONNECTION
108
SCREW DISTRIBUTOR TO CAB
110
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
110
WASHER COMPRESSED AIR LINE TO BRACKET
112
NUT , Replaced By: N913004006001
112
NUT PUMP TO BRACKET
116
HOLLOW SCREW LINE CONNECTION
118
SEAL RING LINE CONNECTION
120
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
120
SCREW PLUG , Replaced By: N000908012009
124
BRACKET (T-FITTING) EXHAUST BRAKE LINE CONNECTION
128
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
130
NUT , Replaced By: N913004006001
130
NUT PUMP TO BRACKET
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
999
T-FITTING EXHAUST BRAKE 3/2-WAY VALVE
999
LOOM TIE BRAKE LINE MOUNTING
999
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
