Поз.
Артикул
Описание
16
ADHESIVE TAPE3X50MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
17
SCREW BRACKET AND CLAMP M6X20
17
SCREW , Replaced By: N914146006102
17
HEXAGON HEAD BOLT
17
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
17
HEXAGON HEAD BOLTM6X80
17
HEXAGON HEAD BOLTM6X60
17
SCREW. HEXAGON HEAD BOLT CONTROL MODULE TO SUPPORT PLATE M6X50
17
HEXAGON HEAD BOLT. SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING
17
SCREW APPARATUS PLATE M 6X45
17
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
20
NUT BRACKET TO FIRE WALL
23
MOUNTING CLAMP22/15
23
CLAMP10/15
23
CLAMP SUCTION/DELIVERY/RETURN LINES 12/15MM
23
CLAMP35/20
23
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 18/15 MM
23
MOUNTING CLAMP28/15
23
CLAMP42/20
23
MOUNTING CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM
23
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
23
CLAMP
23
CLAMP LINE MOUNTING 15-18 MM,V 207570
23
CLAMP22/15, Replaced By: A0019951442
23
CLAMP28/15, Replaced By: A0019951842
23
CLAMP42/20, Replaced By: N000000007548
23
CLAMP SUCTION/DELIVERY/RETURN LINES 15/15 MM, Replaced By: A0019950642
23
CLAMP35/20, Replaced By: N000000007514
25
98
BRACKET
99
BRACKET
271
FLAME PROTECTOR
271
SEALANT310 ML
364
FILLING VALVE ON DELIVERY SIDE
364
VALVE. FILLING VALVE ON SUCTION SIDE
365
CAPTO A 000 832 03 84
365
CAPTO A 000 832 02 84
367
OIL-BREAK SWITCH ON SUCTION SIDE 0,4 BAR
370
PRESSURE MONITOR HIGH PRESSURE 20/25BAR
373
SEALING STRIP , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
376
SEAL RING
379
COOLANT LINE
381
382
385
BRACKET
420
999
CLEANER
