Поз.
Артикул
Описание
15
BRACKET
18
BELT TIGHTENER PULLEY
19
MUFFLER
21
SUPPORT
24
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
27
FAN
30
SHAFT , EXHAUST STOCK OF OLD PART NUMBER FIRST
33
V-BELT2050 MM
36
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
39
SCREWM 10X20
42
SCREW BRACKET TO SUPPORT M 12X25,K 574789
45
NUT HORN TO BRACKET M8
48
HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X65
48
HEXAGON HEAD BOLT. SCREW SUPPORT TO FRAME M14 X 1.5 X 65
51
SCREW SUPPORT TO FRAME M 14X1.5X160
51
HEXAGON HEAD BOLTM14X1.5X160
54
PULLEYDW224/210X127MM
54
PULLEY217X127MM
54
V-BELT PULLEY
57
SCREW STOP TO BATTERY CASE
60
HEXAGON HEAD BOLT SHOCK ABSORBER TO CONSOLE,BOTTOM M12X1.5X80
63
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
66
WASHER PLANE-PARALLEL
69
HEXALOBULAR BOLT WITH HEXALOBULAR SOCKET M8X40
70
FAN DRIVE
70
FAN DRIVE
73
RS BALL BEARING , Replaced By: A0009807415
73
RS BALL BEARING
73
RS BALL BEARINGTO A 000 500 41 22
75
SCREW PLUG WATER DRAIN
76
SCREW PLUG STEERING BOX
78
SEALING RING. SEAL RING ENGINE BREATHING
79
SEAL RING OIL LINE TO OIL COOLER
81
RS MITER GEAR
81
RS COVER MITER GEARING TO A 000 500 41 22
92
NUT
95
PLUG HOUSING 4-POLE
98
BOOT 180 DEGREE OUTLET WITH VARIABLE CLAMPING
101
CONTACT PIN0.5-1.0 MM2
104
WIRE SEAL GREY 0.5-1.0 MM2
107
BREATHER PIPE
119
NUT , Replaced By: N913023006001
122
CLAMP COOLING WATER HOSES
122
CLAMP OIL FILLER PIPE TO BRACKET
125
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
