TOURISMO 16 RHD - 632.035 - 82 ELECTRICAL SYSTEM
Поз.
Артикул
Описание
5
SIDE MARKER LAMP (POSITION LAMP) FRONT TOP,WITHE
8
BULB WITH REINFORCED COILED FILAMENT 24 V/10 W
11
CLIP FASTENER
14
TAPPING SCREW. SCREW4.2X16
17
SHEET METAL SCREW BRACKET TO FLOOR PLATE
20
COVERING
101
FOGLAMP RIGHT
101
FOGLAMP LEFT
104
LENS LEFT
104
LENS RIGHT
107
SEAL LEFT AND RIGHT
110
RETAINING CLAMP. SPRING , Replaced By: A1408260284
113
BULB24V,70W
116
PIN BUSHING HOUSING FOLDING TOP ACTUATION VALVE
119
ROUND PIN BUSHING2.5 MM2
122
HEADLAMP RIGHT
122
HEADLAMP LEFT
125
LENS PARTSKIT,RIGHT
125
LENS PART KIT,LEFT
128
RETAINING CLAMP. SPRING , Replaced By: A1408260284
131
BULBH7 - 24V 70W
134
BULB24V,70W
137
BULB24V-5W
