Поз.
Артикул
Описание
41
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
41
HOSE , Replaced By: A0009872827
44
FITTING (PARTS KIT),LINE RUPTURE
45
CONNECTOR REPAIR SIZE
47
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
50
INSULATING HOSE AIR DEHYDRATOR, ORDER BY THE METER
56
CONNECTOR DISTRIBUTOR TO CAB
59
CONNECTOR DISTRIBUTOR TO FRAME
59
CONNECTOR , Replaced By: A0019903978
62
CONNECTOR DISTRIBUTOR TO CAB
65
CONNECTOR DISTRIBUTOR TO FRAME
68
CONNECTOR DISTRIBUTOR TO FRAME
71
CONNECTOR DISTRIBUTOR TO CAB
74
SEAL RING , Replaced By: A0229973948
74
SEAL RING CONNECTOR 11.8X2 MM
77
SEAL RING
80
PLUG EXHAUST BRAKE VALVE, CONNECTION: "20"
83
NUT EXHAUST BRAKE VALVE, CONNECTION: "20"
86
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
89
NUT STRAP TO SUPPORT
92
BRACKET CONNECTOR TO FRAME
95
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
98
NUT , Replaced By: N913004006001
98
NUT PUMP TO BRACKET
101
SCREW EXHAUST BRAKE SEPARATION POINT
104
DISTRIBUTOR LINE CONNECTION
105
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, M 12X1.5 MM/ 9 MM
110
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
113
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
119
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
122
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
123
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22, 9 MM
124
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
131
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
134
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
140
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
143
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
146
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
149
SCREW. UNION SCREW LINE CONNECTION
