Поз.
Артикул
Описание
5
REAR SPRING (SUPPORTING SPRING),5 LEAVES
8
BUSHING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6753200650
8
BUSHING SPRING EYE,FRONT AND REAR
8
BUSHING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6753200650
11
SHIM , Replaced By: A9703210184
11
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
14
SHIM BETWEEN THE SPRING LEAVES
20
RUBBER BUFFER BETWEEN THE SPRING LEAVES, Replaced By: A3753200844
20
RUBBER BUFFER BETWEEN THE SPRING LEAVES
23
RUBBER BUFFER BETWEEN THE SPRING LEAVES
26
SHIM , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A9703250184
26
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
29
SHIM , Replaced By: A9703250184
29
SHIM BETWEEN THE SPRING LEAVES, TO BE ADAPTED DURING ASSEMBLY
29
SHIM , Replaced By: A9703250184
29
SHIM BETWEEN THE SPRING LEAVES
35
SPRING BOLT
38
NUT , Replaced By: N910113012005
38
HEXAGON NUT. NUT SPRING BOLT
44
SPRING CLAMP
50
SCREW RUBBER BUFFER TO SPRING LEAF
53
NUT , Replaced By: N913002006009
53
NUT OIL TANK TO BRACKET
59
RIVET SPRING CLAMP TO SPRING LEAF
74
THRUST WASHER REAR SPRING TO REAR SPRING FRONT BRACKET
77
SHACKLE (SPRING SHACKLE)
80
BUSHING SPARE WHEEL HOIST TO CROSS MEMBER
80
BUSHING REAR SPRING TO REAR SPRING REAR BRACKET
83
SCREW , Replaced By: N000960018072
83
SCREW VIBRATION ABSORBER TO CONSOLE
86
NUT , Replaced By: N910113018004
86
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
101
PLATE REAR SPRING TO REAR AXLE
104
U-BOLT REAR SPRING TO REAR AXLE 370 MM
107
WASHER FRONT SPRINGS TO FRONT AXLE
110
NUT FRONT SPRINGS WITH TORSION BAR TO FRONT AXLE
113
BRACKET , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6733200243
113
BRACKET AXLE STOP
116
HELPER SPRING RUBBER BUFFER
119
PIN RUBBER BUFFER
122
SCREW , Replaced By: N304017010002
122
SCREW BRACKET TO SIDE MEMBER
125
SHIM BRACKET TO SIDE MEMBER, TO BE ADAPTED DURING ASSEMBLY
128
NUT , Replaced By: N910113010000
128
NUT STRAP TO BRACKET
