Поз.
Артикул
Описание
5
PRESSURE REGULATORKNORR,5 7999995 800000 - 5 8127305 900000 - 5 936365
5
PRESSURE REGULATORWABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
5
PRESSURE REGULATOR WITH TIRE INFLATING CONNECTION BOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
REPAIR KIT PRESSURE REGULATOR WABCO
8
REPAIR KIT DIAPHRAGM PART BOSCH,209
8
REPAIR KITTO 002 431 83 06, KNORR 90309
8
REPAIR KIT SEAL RING BOSCH,209
17
BRAKE ANCHOR PRESSURE REGULATOR TO CROSS MEMBER TO A 002 431 43 06
20
SCREW AIR RESERVOIR BRACKET TO FRAME 3/8-16X1/4 FG 8
23
WASHER SHIFTING ROD 3/8
26
NUT. PART NAME MISSING NUT
29
SCREW 5/16 -1
29
SCREW LINE MOUNTING 5/16-18
32
WASHER VALVE TO BRACKET 5/16-.640
35
PART NAME MISSING NUT
41
ANTI-FREEZE DEVICE
44
FILTER PARTS KIT BW 109578
47
VALVE REPAIR KIT BW 5005037
50
HEATING UNIT PARTS KIT BW 109578
53
VALVE PARTS KIT BW 107800
56
VALVEBW 800405
59
BRACKET PARTS KIT BW 107695
62
VALVEBW 285849
65
PLUGBW 109869
68
HOUSINGBW 112399
71
SCREW AIR RESERVOIR BRACKET TO FRAME 3/8-16X1/4 FG 8
74
WASHER SHIFTING ROD 3/8
77
NUT. PART NAME MISSING NUT
80
T-FITTING
83
ELBOW FITTING90GR. 1/2NPTFX5/8T
86
ELBOW FITTING REGENERATION TANK
999
ELBOW FITTING1/2 NPT X 7/8-14
999
FITTING
999
