Поз.
Артикул
Описание
5
TORSION BAR
5
TORSION BAR , Replaced By: A6883200711
5
TORSION BAR , Replaced By: A6883207811
8
RUBBER MOUNTING TORSION BAR TO FRONT AXLE
11
BRACKET TORSION BAR TO FRONT AXLE
14
CLAMP TORSION BAR TO FRONT AXLE
17
BRACKET TORSION BAR TO FRONT AXLE
17
BRACKET , Replaced By: A6883237040
20
NUT BRACKET TO SIDE MEMBER M12X1.5
23
BRACKET RIGHT
23
BRACKET , Replaced By: A6883200443
23
BRACKET LEFT
23
BRACKET , Replaced By: A6883200343
26
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
29
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
32
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
32
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
35
NUT BRACKET TO SIDE MEMBER M12X1.5
38
BEARING BRACKET TO SHACKLE
38
BEARING BRACKET TO SHACKLE
38
BEARING SHACKLE TO STABILIZER, Replaced By: A9793200173
38
BEARING
38
BEARING
41
SHACKLE
44
HEXAGON HEAD BOLT. SCREW VIBRATION ABSORBER TO CONSOLE M 12X1.5X60
47
NUT BRACKET TO SIDE MEMBER M12X1.5
48
REPAIR KIT TORSION BAR BEARING
50
CONSOLE RIGHT SHOCK ABSORBER
50
CONSOLE LEFT SHOCK ABSORBER
56
NUT BRACKET TO SIDE MEMBER M12X1.5
58
RIVET12X36 MM
58
RIVET12X30 MM
60
SHOCK ABSORBER FRONT AXLE
60
SHOCK ABSORBER , Replaced By: A6883230200
60
SHOCK ABSORBER , Replaced By: A6883230200
62
RUBBER RING TOP AND BOTTOM TO A 6883260200
65
BUSHING TOP
68
SPACER TUBE RUBBER PAD
71
BUSHING BOTTOM
74
SCREW. HEXAGON HEAD BOLT LEAF SPRING TO RUBBER MOUNTING M14X1.5X150
77
HEXAGON HEAD BOLT. SCREW SUPPORT TO FRAME M 14X1.5X90
80
SPACER TUBE SHOCK ABSORBER TO FRONT AXLE
83
WASHER SHOCK ABSORBER TO FRONT AXLE
86
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
86
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
89
RUBBER SPRING FRONT SPRING STOP
92
WASHER RUBBER SPRING TO BRACKET
95
BRACKET RUBBER SPRING TO BRACKET
