Поз.
Артикул
Описание
59
EXPANSION PLUG
98
GASKET TRANSMISSION CASE TOP COVER
98
GASKET SHIFT CASE,TOP,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
98
GASKET , Replaced By: A3812610880
98
GASKET , Replaced By: A3812610280
101
SCREW LINE MOUNTING M 8X45
101
SCREW SHIFTER COVER TO TRANSMISSION CASE M 8X75
104
SPRING WASHER , Replaced By: N000137008212
104
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
158
LOCK PLATE SHIFTING ROD
161
NUT , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817
241
SPRING LOCK-OUT BRACKET
352
SCREW , Replaced By: N304017008021
352
SCREW PIPE CLAMP
358
SPRING WASHER , Replaced By: N000137008212
358
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
364
BREATHER TRANSFER CASE
999
GASKET , Replaced By: A3852613580
999
REPAIR KIT , Replaced By: A3732602633
